LEVER details:

Model YA

Malleable cast iron handle

10position zinc plated steel throtting plate

Model YB

Malleable cast iron handle

10position zinc plated steel throtting plate

Model YC

Malleable cast iron handle

10position ABS throtting plate

Model YD

Aluminum allop handle

10position ABS throtting plate with padlock hole

Model YE

Aluminum allop handle

10position ABS throtting plate with padlock hole

Model YF

Aluminum allop handle

10position ABS throtting plate with padlock hole





VALVE SIZE MODEL YA MODEL YB MODEL YC MODEL YD MODEL YE MODEL YF
L H L H L H L H L H L H
1’’-4’’ 260 25 270 26 210 32 18 32 175 70 198 54
5’’-6’’ 260 25 270 26 260 32 198 32 220 76 278 65
8’’ 360 34 300 28 356 38 300 32 / / 278 65
10’’-12’’ 500 44 360 32 356 32 / / / / / /
